| Image |
Part Number |
Cable |
Center contact |
Outer contact |
Body plating |
Outline drawing |
Data Sheet |
 |
5021.SMA.JSC.01.111 |
UT47 |
Solder |
Solder |
Gold |
 |
|
|
5022.SMA.JSC.02.111 |
UT85, Flexiform405, RG405/U |
Solder |
Solder |
Gold |
|
|
|
5023.SMA.JSC.03.111 |
UT141, Flexiform402, RG402/U |
Solder |
Solder |
Gold |
|
|
|
5173.SMA.JSC.02.111 |
UT85, Flexiform405, RG405/U |
Solder |
Solder |
Gold |
|
|
|
5174.SMA.JSC.03.111 |
UT141, Flexiform402, RG402/U |
Solder |
Solder |
Gold |
|
|
 |
5024.SMA.JSC.05.111 |
RG178B/U, RG196A/U |
Solder |
Crimp |
Gold |
|
|
|
5175.SMA.JSC.05.111 |
RG178B/U, RG196A/U |
Solder |
Crimp |
Gold |
|
|
 |
5025.SMA.JSC.06.111 |
RG174/U, RG188A/U, RG316/U |
Solder |
Crimp |
Gold |
|
|
|
5026.SMA.JSC.07.111 |
RG316D/U |
Solder |
Crimp |
Gold |
|
|
|
5176.SMA.JSC.06.111 |
RG174/U, RG188A/U, RG316/U |
Solder |
Crimp |
Gold |
|
|
|
5177.SMA.JSC.07.111 |
RG316D/U |
Solder |
Crimp |
Gold |
|
|
 |
5027.SMA.JSC.08.111 |
RG58C/U, RG303/U |
Solder |
Crimp |
Gold |
|
|
|
5028.SMA.JSC.09.111 |
RG142B/U, RG223/U, RG400/U |
Solder |
Crimp |
Gold |
|
|
|
5178.SMA.JSC.08.111 |
RG58C/U, RG303/U |
Solder |
Crimp |
Gold |
|
|
|
5179.SMA.JSC.09.111 |
RG142B/U, RG223/U, RG400/U |
Solder |
Crimp |
Gold |
|
|
