| Image |
Part Number |
Cable |
Center contact |
Outer contact |
Body plating |
Outline drawing |
Data Sheet |
 |
4998.SMA.PSC.01.111 |
UT47 |
Solder |
Solder |
Gold |
 |
|
|
4999.SMA.PSC.02.111 |
UT85, Flexiform405, RG405/U |
Solder |
Solder |
Gold |
|
|
|
4999.SMA.PSC.02.141 |
UT85, Flexiform405, RG405/U |
Solder |
Solder |
Passivated |
|
|
|
5000.SMA.PSC.03.111 |
UT141, Flexiform402, RG402/U |
Solder |
Solder |
Gold |
|
|
|
5000.SMA.PSC.03.141 |
UT141, Flexiform402, RG402/U |
Solder |
Solder |
Passivated |
|
|
 |
5001.SMA.PSC.03.111 |
UT141, Flexiform402, RG402/U |
Plug-in |
Solder |
Gold |
|
|
|
5001.SMA.PSC.03.141 |
UT141, Flexiform402, RG402/U |
Plug-in |
Solder |
Passivated |
|
|
 |
5002.SMA.PSC.05.111 |
RG178B/U, RG196A/U |
Solder |
Crimp |
Gold |
|
|
 |
5003.SMA.PSC.06.111 |
RG174/U, RG188A/U, RG316/U |
Solder |
Crimp |
Gold |
|
|
|
5003.SMA.PSC.06.141 |
RG174/U, RG188A/U, RG316/U |
Solder |
Crimp |
Passivated |
|
|
|
5004.SMA.PSC.07.111 |
RG316D/U |
Solder |
Crimp |
Gold |
|
|
|
5004.SMA.PSC.07.141 |
RG316D/U |
Solder |
Crimp |
Passivated |
|
|
 |
5005.SMA.PSC.08.111 |
RG58C/U, RG303/U |
Solder |
Crimp |
Gold |
|
|
|
5005.SMA.PSC.08.141 |
RG58C/U, RG303/U |
Solder |
Crimp |
Passivated |
|
|
|
5006.SMA.PSC.09.111 |
RG142B/U, RG223/U, RG400/U |
Solder |
Crimp |
Gold |
|
|
|
5006.SMA.PSC.09.141 |
RG142B/U, RG223/U, RG400/U |
Solder |
Crimp |
Passivated |
|
|
 |
5180.SMA.PSC.08.111 |
RG58C/U |
Solder |
Clamp |
Gold |
|
|
|
5181.SMA.PSC.09.111 |
RG223/U |
Solder |
Clamp |
Gold |
|
|
